DC-2500MHz Surge Protectors
- BL-23R/BL-23RP
- WLAN,WiFi
- Surge Protectors
- Others
- Others
- Others
- Others
BL-23R/BL-23RP surge protectors，adopting the voltage penetrating through conduction current principle which achieves the good lighting protection effect. The simple & firm structure makes it easy to install.
Specifications | ||
Model | BL-23R | BL-23RP |
Freq. Range-MHz | DC～2500 | |
Max Power-W | 200 | |
Discharge Voltage-V | DC230 | |
Nominal Impedance-Ω | 50 | |
VSWR | ≤1.3 | |
Insertion Loss-dB | ≤0.2 | |
Lightning Protection | Voltage Penetrate Conduction Current | |
Connector Type | N Female | N Female/N Male |
Size-mm | 74x42x20 | |
Weight-kg | 0.1 | |
Temperature--℃ | -40～70 | |
